User Maintenance
18-22 LOGIQ 7 Online Help
Direction 2392536-100 Rev. 1
Cleaning the LOGIQ 7 air filter
Clean the system's air filters to ensure that a clogged filter does
not cause the system to overheat and reduce system
performance and reliability. It is recommended the filters be
cleaned quarterly (once every three months).
Locating The LOGIQ 7 has two air filters. The bottom air filter is located in
the bottom of the system and the LV filter is located behind the
right front caster.
Figure 18-8. Location of Air Filters
1. Bottom Air Filter
2. LV Filter
CAUTION
Be sure to lock the wheels before cleaning the air filters to
avoid injury by any unexpected movement of the system.
1
2
To Next Page
