Hitachi WJ C1 Series User Manual

Chapter 8 Mandatory Setting for Motor Drive and Test Run
8-1-4
 The following parameters and I/O terminal functions cannot be selected for low duty mode.
■ Non-display parameters for low duty mode
Code
Parameter name
Code
Parameter name
[d009]
Torque reference monitor
[H005]
*1
Async. Motor speed response
[d010]
Torque bias monitor
[H020]
*1
Async. Motor constant R1
[d012]
Output torque monitor
[H021]
*1
Async. Motor constant R2
[b040]
Torque limit selection
[H022]
*1
Async. Motor constant L
[b041]
Torque limit 1 (Forward drive)
[H023]
*1
Motor constant I0
[b042]
Torque limit 2 (Reverse regenerative)
[H024]
*1
Async. Motor constant J
[b043]
Torque limit 3 (Reverse drive)
[H030]
*1
Async. Motor constant R1
(Auto-tuning data)
[b044]
Torque limit 4 (Forward regenerative)
[H031]
*1
Async. Motor constant R2
(Auto-tuning data)
[b045]
Torque limit LADSTOP selection
[H032]
*1
Async. Motor constant L
(Auto-tuning data)
[b046]
Direction reversal protection
selection
[H033]
*1
Async. Motor constant I0
(Auto-tuning data)
[C054]
Over/ Under-torque selection
[H034]
*1
Async. Motor constant J
(Auto-tuning data)
[C055]
Over/ Under-torque level
(Forward drive)
[P033]
Torque reference input source
selection
[C056]
Over/ Under-torque level
(Reverse regenerative)
[P034]
Torque reference
[C057]
Over/ Under-torque level
(Reverse drive)
[P036]
Torque bias input source selection
[C058]
Over/ Under-torque level
(Forward regenerative)
[P037]
Torque bias value
[C059]
Over/ Under-torque output signal
mode selection
[P038]
Torque bias polarity selection
[H001]
Auto-tuning selection
[P039]
Speed limit at torque control
(at Forward rotation)
[H002]
*1
Async. Motor constant selection
[P040]
Speed limit at torque control
(at Reverse rotation)
*1. "2nd-motor control [SET]" target parameter.
■ Not selectable I/O terminal function at low duty mode
Input terminal function
Output terminal function
40: TL
Torque limit enable
07: OTQ
Over-torque/under-torque
41: TRQ1
Torque limit selection bit 1
10: TRQ
Torque limited
42: TRQ2
Torque limit selection bit 2
-
-
52:ATR
Permission of torque control
-
-
!
