Hitachi WJ C1 Series User Manual

Chapter 1 Safety Instructions/Risks
1-4-1
1.4 Compliance to UL Standards
1.4.1 UL Cautions
This section summarizes the items required for UL standard compliant inverter installation.
GENERAL:
WJ series C1 inverter is open type AC Inverter with three/single phase input and three phase
output. It is intended to be used in an enclosure. It is used to provide both an adjustable voltage
and adjustable frequency to the AC motor. The inverter automatically maintains the required
volts-Hz ratio allowing the capability through the motor speed range. It is multi-rated device,
and the ratings are selectable according to load types by operator with keypad operation.
Markings:
Maximum Surrounding Temperature:
 ND (Normal Duty): 50 deg C
 LD (Low Duty) : 40 deg C
Storage Environment rating:
 - 65 deg C (for transportation)
Instruction for installation:
 Pollution degree 2 environment and Overvoltage category 3
Electrical Connections:
 See "5.2 Main Circuit Terminal".
Interconnection and wiring diagrams:
 See "5.4 Control Circuit Terminal".
Short circuit rating and overcurrent protection device rating:
 C1-S series, C1-001SF to C1-022SF models.
- [Non-semiconductor Fuses]
Suitable for use on a circuit capable of delivering not more than 5,000 rms symmetrical
amperes, 240 V maximum.
- [Semiconductor Fuses]
Suitable for use on a circuit capable of delivering not more than 100,000 rms
symmetrical amperes, 240 V maximum.
 C1-L series, C1-001LF to C1-037LF models.
- [Non-semiconductor Fuses]
Suitable for use on a circuit capable of delivering not more than 5,000 rms symmetrical
amperes, 240 V maximum.
 C1-L series, C1-055LF and C1-075LF models.
- [Non-semiconductor Fuses]
Suitable for use on a circuit capable of delivering not more than 5,000 rms symmetrical
amperes, 240 V maximum.
 C1-L series, C1-110LF and C1-150LF models.
- [Non-semiconductor Fuses]
Suitable for use on a circuit capable of delivering not more than 5,000 rms symmetrical
amperes, 240 V maximum.
 C1-L series, C1-001LF to C1-150LF models.
- [Semiconductor Fuses]
Suitable for use on a circuit capable of delivering not more than 100,000 rms
symmetrical amperes, 240 V maximum.
 C1-H series, C1-004HF to C1-075HF models.
- [Non-semiconductor Fuses]
Suitable for use on a circuit capable of delivering not more than 5,000 rms symmetrical
amperes, 480 V maximum.
 C1-H series, C1-110HF and C1-150HF models.
- [Non-semiconductor Fuses]
Suitable for use on a circuit capable of delivering not more than 5,000 rms symmetrical
amperes, 480 V maximum.
 C1-H series, C1-004HF and C1-150HF models.
- [Semiconductor Fuses]
Suitable for use on a circuit capable of delivering not more than 100,000 rms
symmetrical amperes, 480 V maximum.
Integral:
 Integral solid state short circuit protection does not provide branch circuit protection. Branch
circuit protection must be provided in accordance with the National Electrical Code and any
additional local codes.
Integral:
 Integral solid state short circuit protection does not provide branch circuit protection. Branch
circuit protection must be provided in accordance with the Canadian Electrical Code, Part 1.
(For Canada)
