Hitachi WJ C1 Series User Manual

Chapter 1 Safety Instructions/Risks
1-4-2
■ Field wiring conductor size and torque values making for wiring terminal
Model
Screw Size
Required Torque
(N･m)
Wire Rang
(AWG/mm
2
)
C1-001S
M3.5
1.0
AWG16 (1.3 mm
2
)
C1-002S
M3.5
1.0
AWG16 (1.3 mm
2
)
C1-004S
M3.5
1.0
AWG16 (1.3 mm
2
)
C1-007S
M4
1.4
AWG12 (3.3 mm
2
)
C1-015S
M4
1.4
AWG10 (5.3 mm
2
)
C1-022S
M4
1.4
AWG10 (5.3 mm
2
)
C1-001L
M3.5
1.0
AWG16 (1.3 mm
2
)
C1-002L
M3.5
1.0
AWG16 (1.3 mm
2
)
C1-004L
M3.5
1.0
AWG16 (1.3 mm
2
)
C1-007L
M3.5
1.0
AWG16 (1.3 mm
2
)
C1-015L
M4
1.4
AWG14 (2.1 mm
2
)
C1-022L
M4
1.4
AWG12 (3.3 mm
2
)
C1-037L
M4
1.4
AWG10 (5.3 mm
2
)
C1-055L
M5
3.0
AWG6 (13 mm
2
)
C1-075L
M5
3.0
AWG6 (13 mm
2
)
C1-110L
M6
3.9 to 5.1
AWG4 (21 mm
2
)
C1-150L
M8
5.9 to 8.8
AWG2 (34 mm
2
)
C1-004H
M4
1.4
AWG16 (1.3 mm
2
)
C1-007H
M4
1.4
AWG16 (1.3 mm
2
)
C1-015H
M4
1.4
AWG16 (1.3 mm
2
)
C1-022H
M4
1.4
AWG14 (2.1 mm
2
)
C1-030H
M4
1.4
AWG14 (2.1 mm
2
)
C1-040H
M4
1.4
AWG12 (3.3 mm
2
)
C1-055H
M5
3.0
AWG10 (5.3 mm
2
)
C1-075H
M5
3.0
AWG10 (5.3 mm
2
)
C1-110H
M6
3.9 to 5.1
AWG6 (13 mm
2
)
C1-150H
M6
3.9 to 5.1
AWG6 (13 mm
2
)
Temperature rating of field wiring installed conductor:
 For models C1-001S, C1-002S, C1-004S, C1-007S, C1-015S, C1-001L, C1-004L, C1-007L,
C1-015L, C1-004H, C1-007H, C1-015H, C1-022H, C1-030H and C1-040H
- 60 degree C only.
 Except above models - 75 degree C only.
Field wiring Terminal marking for wire type:
 Use copper conductors only
