Chapter 18 List of Parameters/Modbus Coil/Register Numbers
18-2-7
Manual torque
boost value, 1st-
motor
Manual torque
boost value, 2nd-
motor
Manual torque
boost peak
speed, 1st-motor
Manual torque
boost peak
speed, 2nd-
motor
Control mode
selection, 1st-
motor
00: [V/f] Constant torque
characteristics (IM)
01: [V/f] Reducing torque
characteristics (IM)
02: [V/f] Free V/f (IM)
03: Sensorless vector control
(SLV) (IM) (Selectable only
at ND)
Control mode
selection, 2nd-
motor
Output voltage
gain, 1st-motor
Output voltage
gain, 2nd-motor
Automatic torque
boost voltage
compensation
gain, 1st-motor
Automatic torque
boost voltage
compensation
gain, 2nd-motor
Automatic torque
boost slip
compensation
gain, 1st-motor
Automatic torque
boost slip
compensation
gain, 2nd-motor
00: Disable
01: Enable
02: Enable (Output frequency
< [A052])
0 to 100 (%) (Normal duty (ND))
0 to 70 (%) (Low duty (LD))
0 to 100 (ND)
0 to 70 (LD)
DC braking active
time at stop
DC braking
operation
method selection
00: Edge operation
01: Level operation
DC braking force
at start
0 to 100 (%) (Normal duty (ND))
0 to 70 (%) (Low duty (LD))
0 to 100 (ND)
0 to 70 (LD)
DC braking active
time at start
Carrier frequency
during DC
braking
*4
2.0 to 15.0 (kHz)
(Normal duty (ND))
2.0 to 10.0 (kHz)
(Low duty (LD))
20 to 150 (ND)
20 to 100 (LD)
*2. The default settings when initialize by setting 00/01/03 to "Initialize data selection [b085]".
*4. This parameter is a dummy parameter. User setting is disabled. Carrier frequency in DC braking is shared with
"Carrier frequency [b083]". In addition, if data is written within the data range by Modbus communication, no
error will occur.
