Hitachi WJ C1 Series User Manual

Chapter 18 List of Parameters/Modbus Coil/Register Numbers
18-2-6
Code
Name
Data range
Initial
value
Set
value
Change
during
running
Modbus communication
Page
Register No.
Data Range
Resolution
P075
Position control
mode selection
00: Limit
01: No limit
00
×
1657h
0 to 1
-
9-14-2
P077
Encoder
disconnection
timeout
0.0 to 10.0 (s)
1.0
✓
1659h
0 to 100
0.1
15-2-6
P080
Positioning
restart range
0 to 10000 (pulse)
* Set by multiplying by 4.
0
×
165Ch
0 to 10000
1
9-14-2
P081
Save current
position at power
off
00: Disable
01: Enable
00
✓
165Dh
0 to 1
-
9-14-11
P082
Current position
at power off
Position control range
(reverse) [P073] to Position
control range (forward) [P072]
(pls)
0
✓
165Eh (High)
165Fh (Low)
Position control
range (reverse)
[P073] to Position
control range
(forward) [P072]
1
P083
Pre-set position
data
Position control range
(reverse) [P073] to Position
control range (forward) [P072]
(pls)
0
✓
1660h (High)
1661h (Low)
Position control
range (reverse)
[P073] to Position
control range
(forward) [P072]
1
9-14-10
P100
EzSQ user
parameter U(00)
0 to 65535
0
✓
1666h
0 to 65535
1
12-2-3
P101
EzSQ user
parameter U(01)
0 to 65535
0
✓
1667h
0 to 65535
1
P102
EzSQ user
parameter U(02)
0 to 65535
0
✓
1668h
0 to 65535
1
P103
EzSQ user
parameter U(03)
0 to 65535
0
✓
1669h
0 to 65535
1
P104
EzSQ user
parameter U(04)
0 to 65535
0
✓
166Ah
0 to 65535
1
P105
EzSQ user
parameter U(05)
0 to 65535
0
✓
166Bh
0 to 65535
1
P106
EzSQ user
parameter U(06)
0 to 65535
0
✓
166Ch
0 to 65535
1
P107
EzSQ user
parameter U(07)
0 to 65535
0
✓
166Dh
0 to 65535
1
P108
EzSQ user
parameter U(08)
0 to 65535
0
✓
166Eh
0 to 65535
1
P109
EzSQ user
parameter U(09)
0 to 65535
0
✓
166Fh
0 to 65535
1
P110
EzSQ user
parameter U(10)
0 to 65535
0
✓
1670h
0 to 65535
1
P111
EzSQ user
parameter U(11)
0 to 65535
0
✓
1671h
0 to 65535
1
P112
EzSQ user
parameter U(12)
0 to 65535
0
✓
1672h
0 to 65535
1
P113
EzSQ user
parameter U(13)
0 to 65535
0
✓
1673h
0 to 65535
1
P114
EzSQ user
parameter U(14)
0 to 65535
0
✓
1674h
0 to 65535
1
P115
EzSQ user
parameter U(15)
0 to 65535
0
✓
1675h
0 to 65535
1
P116
EzSQ user
parameter U(16)
0 to 65535
0
✓
1676h
0 to 65535
1
P117
EzSQ user
parameter U(17)
0 to 65535
0
✓
1677h
0 to 65535
1
P118
EzSQ user
parameter U(18)
0 to 65535
0
✓
1678h
0 to 65535
1
P119
EzSQ user
parameter U(19)
0 to 65535
0
✓
1679h
0 to 65535
1
P120
EzSQ user
parameter U(20)
0 to 65535
0
✓
167Ah
0 to 65535
1
P121
EzSQ user
parameter U(21)
0 to 65535
0
✓
167Bh
0 to 65535
1
P122
EzSQ user
parameter U(22)
0 to 65535
0
✓
167Ch
0 to 65535
1
P123
EzSQ user
parameter U(23)
0 to 65535
0
✓
167Dh
0 to 65535
1
P124
EzSQ user
parameter U(24)
0 to 65535
0
✓
167Eh
0 to 65535
1
P125
EzSQ user
parameter U(25)
0 to 65535
0
✓
167Fh
0 to 65535
1
