Chapter 18 List of Parameters/Modbus Coil/Register Numbers
18-2-8
Code
Name
Data range
Initial
value
Set
value
Change
during
running
Modbus communication
Page
Register No.
Data Range
Resolution
P173
Flexible command
reading register 4
0000h to FFFFh
0000
✓
16AFh
0000h to
FFFFh
1
13-2-2
P174
Flexible command
reading register 5
0000h to FFFFh
0000
✓
16B0h
0000h to
FFFFh
1
P175
Flexible command
reading register 6
0000h to FFFFh
0000
✓
16B1h
0000h to
FFFFh
1
P176
Flexible command
reading register 7
0000h to FFFFh
0000
✓
16B2h
0000h to
FFFFh
1
P177
Flexible command
reading register 8
0000h to FFFFh
0000
✓
16B3h
0000h to
FFFFh
1
P178
Flexible command
reading register 9
0000h to FFFFh
0000
✓
16B4h
0000h to
FFFFh
1
P179
Flexible command
reading register 10
0000h to FFFFh
0000
✓
16B5h
0000h to
FFFFh
1
P180
PROFIBUS Node
address
0 to 125
0
×
16B6h
0 to 12
1
P181
PROFIBUS Clear
Mode selection
00: Clear
01: Keep last value
00
×
16B7h
0 to 1
-
P182
PROFIBUS Map
selection
00: PPO type
01: Conventional
02: Flexible mode
00
×
16B8h
0 to 2
-
P185
CANopen Node
address
0 to 127
0
×
16BBh
0 to 127
1
-
P186
CANopen Baud
rate
00: Auto
01: 10kbps / 02: 20kbps
03: 50kbps / 04: 125kbps
05: 250kbp / 06: 500kbps
07: 800kbp / 08: 1Mbps
06
×
16BCh
0 to 8
-
-
P190
CompoNet Node
address
00 to 63
0
×
16C0h
0 to 63
1
-
P192
DeviceNet MAC
ID
00 to 63
63
×
16C2h
0 to 63
1
-
P195
ML2 frame length
00: 32bytes / 01: 17bytes
00
×
16C5h
0 to 1
-
-
P196
ML2 Node
address
21h to 3Eh
21h
×
16C6h
21 to 3Eh
1
-
P200
Register mapping
selection
00: Standard Modbus address
01: Enable Modbus mapping
function
00
✓
16C8h
0 to 1
-
11-3-1
P201
External register 1
0000h to FFFFh
0000h
✓
16C9h
0000h to
FFFFh
1
P202
External register 2
0000h to FFFFh
0000h
✓
16CAh
0000h to
FFFFh
1
P203
External register 3
0000h to FFFFh
0000h
✓
16CBh
0000h to
FFFFh
1
P204
External register 4
0000h to FFFFh
0000h
✓
16CCh
0000h to
FFFFh
1
P205
External register 5
0000h to FFFFh
0000h
✓
16CDh
0000h to
FFFFh
1
P206
External register 6
0000h to FFFFh
0000h
✓
16CEh
0000h to
FFFFh
1
P207
External register 7
0000h to FFFFh
0000h
✓
16CFh
0000h to
FFFFh
1
P208
External register 8
0000h to FFFFh
0000h
✓
16D0h
0000h to
FFFFh
1
P209
External register 9
0000h to FFFFh
0000h
✓
16D1h
0000h to
FFFFh
1
P210
External register 10
0000h to FFFFh
0000h
✓
16D2h
0000h to
FFFFh
1
P211
External register 1
format
00: Unsigned word data
01: Signed word data
00
✓
16D3h
0 to 1
-
P212
External register 2
format
00: Unsigned word data
01: Signed word data
00
✓
16D4h
0 to 1
-
P213
External register 3
format
00: Unsigned word data
01: Signed word data
00
✓
16D5h
0 to 1
-
P214
External register 4
format
00: Unsigned word data
01: Signed word data
00
✓
16D6h
0 to 1
-
P215
External register 5
format
00: Unsigned word data
01: Signed word data
00
✓
16D7h
0 to 1
-
P216
External register 6
format
00: Unsigned word data
01: Signed word data
00
✓
16D8h
0 to 1
-
