Hitachi WJ C1 Series User Manual

Appendix
A-1-2
WJ200
WJ-C1
Single-phase 200 V 007SF/015SF/022SF
Three-phase 200 V 0015LF/022LF
Three-phase 400 V 004HF/007HF/015HF
/022HF/030HF
Single-phase 200 V 007SF/015SF/022SF
Three-phase 200 V 0015LF/022LF
Three-phase 400 V 004HF/007HF/015HF
/022HF/030HF
Model
W
(mm)
H
(mm)
D
(mm)
D1
(mm)
D2
(mm)
WJ200-007SF
108
128
170.5
55
4.4
WJ200-015SF
WJ200-022SF
WJ200-015LF
WJ200-022LF
WJ200-004HF
143.5
28
4.3
WJ200-007HF
170.5
55
4.4
WJ200-015HF
WJ200-022HF
WJ200-030HF
Model
W
(mm)
H
(mm)
D
(mm)
D1
(mm)
D2
(mm)
C1-007SF
108
128
170.5
55.5
4.5
C1-015SF
C1-022SF
C1-015LF
C1-022LF
C1-004HF
143.5
28.5
C1-007HF
170.5
55.5
C1-015HF
C1-022HF
C1-030HF
4.5 (D2)
D1
D
(9.5)
96
108 (W)
118
128 (H)
2-φ4.5
2-4.5
108 (W)
128 (H)
