Appendix
A-1-10
â–  Three-phase 200 V 11 kW, Three-phase 400 V 11 kW/15 kW
WJ200-110LF/110HF/150HF
C1-110LF/110HF/150HF
â–  Three-phase 200V 15kW
WJ200-150LF
C1-150LF
Screw size
M6
Terminal block width
17.5 mm
Ground
terminal
Short-
circuit
bar
Power supply input wire
Motor output wire
W/T3
V/T2
U/T1
P/+
T/L3
S/L2
R/L1
N/-
RB
G
G
Screw size
M6
Terminal block width
16.5 mm
Ground
terminal
Short-
circuit
bar
Power supply input wire
Motor output wire
W/T3
V/T2
U/T1
P/+
T/L3
S/L2
R/L1
N/-
RB
G
G
Screw size
M8
Terminal block width
23 mm
Ground
terminal
Short-
circuit
bar
Power supply input wire
Motor output wire
W/T3
V/T2
U/T1
P/+
T/L3
S/L2
R/L1
N/-
RB
G
G
Screw size
M8
Terminal block width
23 mm
Ground
terminal
Short-
circuit
bar
Power supply input wire
Motor output wire
W/T3
V/T2
U/T1
P/+
T/L3
S/L2
R/L1
N/-
RB
G
G
Charge
lamp
Charge
lamp
Charge
lamp
Charge
lamp
