D2 Series Servo Drive User Manual Wiring
HIWIN MIKROSYSTEM CORP. 4-21
MD07UE01-2005
 denotes the cable length as follows:
Table4.2.4
 03 05 07 10
Wire Length (m)
3
5
7
10
Note:
The encoder cable shall be chosen to match with the motor encoder.
 Control signal cable
Table4.2.5
Part Name Part No. Description
Control signal cable LMACK02D
2 m in length. Connected to host controller. The cable at
the controller terminal is free and can be soldered
to make
the connector based on the connector of host controller.
Extension I/O signal
cable
HE00834S1200
3 m in length. Connected to host controller. The cable at
the controller terminal is free and can be soldered
to make
the connector based on the connector of host controller.
 Communication cable
Table4.2.6
Part Name Part No. Description
USB communication cable 051700800366
USB 2.0 Type A to mini-B 5 pin. 1.8 m in length. The
cable at the drive terminal is the mini-B connector.
Modbus communication
cable
HE00834S0800
0.3 m in length. Suitable for frame A-C models.
HE00834S0900
1 m in length. Suitable for frame A-C models.
HE00834S1000
2 m in length. Suitable for frame A-C models.
HE00834S1100
3 m in length. Suitable for frame A-C models.
HE00834S1300
0.3 m in length. Suitable for the frame D model.
HE00834S1400 1 m in length. Suitable for the frame D model.
HE00834S1500
2 m in length. Suitable for the frame D model.
HE00834S1600
3 m in length. Suitable for the frame D model.
