Wiring D2 Series Servo Drive User Manual
4-22 HIWIN MIKROSYSTEM CORP.
MD07UE01-2005
 Connector kit
Table4.2.7
D2 Drive Model Model No. Description Quantity
Frame A-C D2-CK3
CN1: Connectors of AC power, motor power, regenerative
resistor, and control power. 12 pins, pitch 5 mm, Wago
721-112/026-000.
1
CN2: Brake connector. 4 pins, pitch 3.5 mm
1
CN6: Control signal connector. 50 pins, welded type,
EUMAX XDR-10350AS.
1
CN1 connector fixture tool: Wago 231-131.
1
CN2 connector fixture tool: Wago 734-230.
1
Frame D
(with Modbus
interface)
D2-CK4
CN1: Connectors of AC power, drive control power,
regenerative resistor, and DC reactor. 11 pins, TE
1-2229794-1-PT1.
1
CN2: Motor power connector. 3 pins,
TE 3-22297894-1.
1
CN4: Connector kit for serial communication.
TE 2040008-1.
1
CN5: Safety function connector. TE 1971153-1.
1
CN6: Control signal connector. 50 pins, welded type,
EUMAX XDR-10350AS.
1
CN1 and CN2 connector fixture tools: TE 1981045-1.
2
Frame D D2-CK5
CN1: Connectors of AC power, drive control power,
regenerative resistor, and DC reactor. 11 pins, TE
1-2229794-1-PT1.
1
CN2: Motor power connector. 3 pins,
TE 3-22297894-1.
1
CN5: Safety function connector. TE 1971153-1.
1
CN6: Control signal connector. 50 pins welded type, EUMAX
XDR-10350AS.
1
CN1 and CN2 connector fixture tools: TE 1981045-1.
2
