D2 Series Servo Drive User Manual Wiring
HIWIN MIKROSYSTEM CORP. 4-23
MD07UE01-2005
 EMC accessory kit
Table4.2.8
Part Name Model No. Description Quantity
D2 EMC accessory
kit for single phase
D2-EMC1
Single-phase filter: FN2090-6-06 for 50 W to 400 W.
(Rated current: 6 A, leakage current: 0.67 mA)
1
EMI core KCF-130-B.
2
D2-EMC3
Single-phase filter FN2090-10-06 for 750 W to 1 KW.
(Rated current: 10 A, leakage current: 0.67 mA)
1
EMI core KCF-130-B
2
D2 EMC accessory
kit for three-phase
D2-EMC2
Three-phase filter: FN3025HL-20-71.
(Rated current: 20 A, leakage current: 0.4 mA)
1
EMI core KCF-130-B.
2
D2-EMC4
Three-phase filter B84743C0035R166.
(Rated current: 35 A, leakage current: < 0.5 mA)
1
EMI core KCF-130-B
2
Note:
The EMI magnetic ring can reduce the noise interference, and can be applied on the main power cable, motor
power cable, encoder cable, or pulse control cable based on demand.
 Regenerative resistor
Table4.2.9
Part Name Model No. Resistance Value Rated Power/Peak Power
Regenerative resistor
RG1
68 Ω
100W/500W
RG2
120 Ω
300W/1500W
