Wiring D2 Series Servo Drive User Manual
4-24 HIWIN MIKROSYSTEM CORP.
MD07UE01-2005
 Connector specifications
Table4.2.10 Connector specifications for frame A-C models
Connector Specifications HIWIN Parts No. Wire Diameter Remarks
AC main power cable (CN1)
EU 12-pin 5.0 mm
pluggable female
connector
051500400269
WAGO:
2092-1112
12-24 AWG
Recommended:
12 AWG/600 V
(Note 1)
Motor power cable (CN1)
Regenerative resistor (CN1)
Control power cable (CN1)
Control signal cable (CN6)
50-pin, .050" Mini D
Ribbon (MDR),
standard solder
connector
051500400272
SCSI 50 pin (male)
24-30 AWG (Note 1)
Encoder cable (CN7)
HIWIN standard
encoder cable
Brake signal (CN2)
EU 3-pin 2.5 mm
pluggable female
connector
051500400251
WAGO:
733-103
20-28 AWG
Fixture tool:
733-130
(Note 1)
Mini USB communication (CN3)
USB 2.0 Type A to
mini-B 5 pin (1.8 m)
(Shielding)
051700800366 Optional
Note:
(1) The accessory kit includes connectors of CN1, CN2, and CN6 (with 733-130 fixture tool). HIWIN P/N:
051800200070.
(2) Turn off all power and use fixture tools to avoid electric shock at wiring.
Table4.2.11 Connector specifications for the frame D model
Connector Specifications HIWIN Parts No. Wire Diameter
AC main power (CN1)
D3950/single-row 11 Port/
7.5 mm/Line end/X key
051500400573
TE Connectivity
1-2229794-1
22-14 AWG
Recommended:
14 AWG/600 V
Control power (CN1)
Regenerative resistor (CN1)
DC reactor (CN1)
Motor power cable (CN2)
D3950/single-row 3 Port/
7.5 mm/Line end/X key
051500400572
TE Connectivity
3-2229794-1
22-14 AWG
Recommended:
14 AWG/600 V
RS485 communication (CN4)
Industrial mini I/O plug connector kit
D-shape
type 2
051500400544
TE Connectivity
2040008-1
24-14 AWG
Safety bypass (CN5)
Industrial mini I/O bypass
connector type 1
051500400545
TE Connectivity
1971153-1
