The boot-drive cable and the high-speed SAS-adapter cable are shown in Figure 125.

1 Boot-disk SAS cable that is plugged into the disk-drive backplane to support drive bay 4

2 High-speed SAS-adapter cable that is plugged into the middle of the backplane to support

drive bays 0, 1, 2, and 3

4. Reconnect the boot-disk SAS cable to the SAS disk controller.

The boot-drive cable and the high-speed SAS-adapter cable are shown in Figure 126 on page 123.

Figure 125. Boot-disk SAS cable and the high-speed SAS cable connected to the disk backplane in the SAN Volume

Controller 2145-CF8

122 IBM SAN Volume Controller Hardware Maintenance Guide
