SATA 0 connector

Power connector P1

Front USB connector

Operator-information panel connector

Power connector P6

Fan 5 connector

Fan 4 connector

Microprocessor connector

Fan 3 connector

Fan 2 connector

Fan 1 connector

IDE connector

8. Disconnect and remove both SATA disk cables from sockets SATA 0 and SATA from the system

board, as shown in Figure 266.

9. Remove power connectors P1

and P6

, as shown in Figure 267 on page 245.

Figure 266. SAN Volume Controller 2145-8A4 SATA cable connectors

244 IBM SAN Volume Controller Hardware Maintenance Guide
