Table 15. SAN Volume Controller 2145-8F2 frame assembly (continued)
Assembly index Part number Units Description
-7 13M8293 2 Microprocessor, 3.0 GHz
-8 90P5282 1 Heat sink retention module
- 90P5284 1 Chassis
- 23K4209 1 Cage assembly
-9 32R1730 1 System board
-10 24R2698 2 VRM, 1U/75A
-11 24R2640 1 Power supply assembly
- 23K4515 1 Power backplane
- 33F8354 1 Battery, 3.0V
- 33P2352 1 Cable, fan power
- 25R4052 1 Cable, signal, front panel
-12 23K4992 1 Fan holder with fan
backplanes
-13 23K4490 1 Operator information panel
-15 23K4217 3 Fan, 40×40×28
-16 33P2335 4 Fan, 40×40×56
- 73P2870 8 Memory, 1 GB ECC DRR2
Table 16. Items not included in the SAN Volume Controller 2145-8F2 frame assembly
Assembly index Part number Units Description
-2 64P7783 1 Fibre-channel HBA (full
height)
-5 64P7813 1 Fibre-channel HBA (low
profile)
- 23R2770 1 Fibre-channel SFP
transceiver
-14 64P7874 1 Service controller
- 64P7940 1 Input power cable
assembly, (SAN Volume
Controller 2145-8F2 to the
2145 UPS-1U)
- 23K4218 1 Kit, toolless rail
- 39M5699 External fibre-channel
cable, LC–LC, 1.0 m (3.3 ft)
- 39M5700 External fibre-channel
cable, LC–LC, 5.0 m (16.4
ft)
- 39M5701 External fibre-channel
cable, LC–LC, 25.0 m (82 ft)
- 12R9321 External fibre-channel
cable, LC–SC/LC, 1.0 m
(3.3 ft)
Chapter 1. Parts listing 15
