Table 4. FRUs to which SAN Volume Controller 2145-CF8 service procedures do not refer
Description Part number Quantity
Top cover 43V6933 1
Front panel moulding that surrounds the operator information panel 49Y4818 1
Air baffle kit (microprocessor and memory) 43V6931 1
Heat sink 49Y4820 1
Base chassis 49Y4813 1
Rail kit used to install the node in a rack 49Y4816 1
Cable management arm assembly 49Y4817 1
Cable retention bracket 31P1243 1
Front panel USB cable 43V6920 1
Front bezel assembly 49Y4818 1
DVD drive bay filler 49Y4824 1
240VA safety cover 49Y4823 1
HDD I2C signal cable 43V7023 1
Table 5. FRU parts for the long-wave small form-factor pluggable (SFP) transceiver feature
Description
Part
number
Quantity Feature Code
Long-wave SFP transceiver FRU
Long-wave SFP transceiver that provides an auto-negotiating 2, 4, or 8
gigabits-per-second 10 kilometer (km) long-wave optical connection on
the 4-port fibre-channel adapter.
Note: It is possible that SFP transceiver other than those shipped with
the product are in use on the fibre-channel host bus adapter. It is a
customer responsibility to obtain replacement parts for such SFP
transceiver. The FRU part number is shown as “Non standard - supplied
by customer” in the vital product data.
31P1345 1 to 4 5608
SAN Volume Controller 2145-8A4 parts
You might need to replace a SAN Volume Controller 2145-8A4 field replaceable unit (FRU).
Figure 2 on page 6 shows how the different parts of the SAN Volume Controller 2145-8A4 are assembled.
Chapter 1. Parts listing 5
