Table 3. FRUs in the SAN Volume Controller 2145-CF8 parts assembly (continued)
Assembly
index Part number Units Description
-13 44E8690 1 Disk controller
SAS controller card for the SAS 2.5 inch disk drive that also
includes the riser card.
-14 44E8690 1 Disk controller / USB riser card
Riser card that connects the disk controller to the system board
and provides the USB port to which the service controller cable
connects.
-15 46D1266 1 Microprocessor
2.40 GHz Quad-core microprocessor
Note: This part is the microprocessor only. When replaced, you
must also have alcohol wipes and thermal grease.
- 31P1338 4 Short-wave SFP transceivers
Small form-factor pluggable (SFP) fibre-channel transceiver that
provides an auto-negotiating 2, 4, or 8 gigabits-per-second
short-wave optical connection on the 4-port fibre-channel adapter.
Note: It is possible that SFP transceivers other than those shipped
with the product are in use on the fibre-channel host bus adapter.
It is a customer responsibility to obtain replacement parts for such
SFP transceivers. The FRU part number is shown as “Non
standard - supplied by customer” in the vital product data.
- 31P1206 1 Service controller cable
The USB cable used to connect the service controller to the system
board.
- 43V6922 1 Disk signal cable
200 mm SAS disk signal cable
- 46C4148 1 Disk power cable
SAS disk power cable
- 31P1294 1 Power cable assembly
The cable assembly that connects the SAN Volume Controller and
the 2145 UPS-1U. The assembly consists of two power cables
bundled with a serial cable.
- 49Y4817 1 Cable-management arm
- 46C4139 1 Operator information panel cable
Cable that connects the operator information panel to the system
board
- 41Y9292 - Thermal grease
Grease that helps provide a thermal seal between the processor
and the heat sink
- 59P4739 - Alcohol wipe
Cleaning wipe
4 IBM SAN Volume Controller Hardware Maintenance Guide
