TRAKKER Antares 2420 and 2425 Hand-Held Terminal User’s Manual
Co de 39
Nugget
2-30
Opening the Battery Door
242XU.079
Battery door
latch
TOP
BOTTOM
4. Remove the main battery pack. For help, see “Removing and Installing the Main
Battery Pack” earlier in this chapter.
5. Hold each of the backup battery connectors and gently pull to disconnect the backup
battery.
242XU.086
Battery wire
connectors
Backup
battery
6. Holding the visible end of the backup battery, slide the battery up and out of the
battery compartment. Continue with the next instructions to install the new backup
battery.
