Juniper EX9208 - Chapter 7 Planning Power Requirements; Power Requirements for EX9200 Switch Components; Table 41: EX9200 Switch Component Power Requirements

CHAPTER 7
Planning Power Requirements
•
Power Requirements for EX9200 Switch Components on page 91
•
AC Power Supply Specifications for EX9208 Switches on page 92
•
AC Power Cord Specifications for an EX9208 Switch on page 93
•
DC Power Supply Specifications for EX9208 Switches on page 96
•
Grounding Cable and Lug Specifications for EX9200 Switches on page 97
•
Calculating the EX Series Switch Fiber-Optic Cable Power Budget on page 99
•
Calculating the EX Series Switch Fiber-Optic Cable Power Margin on page 100
Power Requirements for EX9200 Switch Components
Table 41 on page 91 lists the power requirements for different hardware components of
EX9200 switches.
Table 41: EX9200 Switch Component Power Requirements
Reserved Power (watt)Typical Power (watt)Component
•
EX9204 switch: 410 W
•
EX9208 switch: 560 W
•
EX9214 switch: 1670 W
•
EX9204 switch: 410 W
•
EX9208 switch: 560 W
•
EX9214 switch: 1290 W
Base system
•
EX9204 switch: 690 W
•
EX9208 switch: 800 W
•
EX9214 switch: 1910 W
•
EX9204 switch: 690 W
•
EX9208 switch: 800 W
•
EX9214 switch: 1530 W
Redundant system
150 W150 WEX9200-SF Switch Fabric
module
155 W155 WEX9200-SF2 Switch Fabric
module
90 W90 WRouting Engine module (RE
module)
610 W530 WEX9200-2C-8XS line card
520 W408 WEX9200-4QS line card
91Copyright © 2017, Juniper Networks, Inc.
