Figure 62: Installing the Upper Fan Tray in an EX9214 Switch

g022047

NOTE: If you have a Juniper J-Care service contract, register any addition,

change, or upgrade of hardware components at

https://www.juniper.net/customers/support/tools/updateinstallbase/ . Failure

to do so can result in significant delays if you need replacement parts. This

note does not apply if you replace existing components with the same type

of component.

Documentation

Removing a Fan Tray from an EX9200 Switch on page 212•

• Cooling System and Airflow in an EX9204 Switch

• Cooling System and Airflow in an EX9208 Switch on page 39

• Cooling System and Airflow in an EX9214 Switch

• Field-Replaceable Units in an EX9200 Switch on page 16

Chapter 16: Replacing Cooling System Component
