Juniper EX9208 Hardware Guide

This topic describes:
•
Line Card Models on page 59
•
Line Card Components on page 60
Line Card Models
Table 27 on page 59 shows the model number, description of the line card model, and
the Junos OS release in which the line card was first supported.
Table 27: EX9200-MPC
Junos OS
Release
RequiredDescriptionModel
15.1R3A modular line card that accepts any of the following Modular
Interface Cards (MICs):
•
EX9200-10XS-MIC
•
EX9200-20F-MIC
•
EX9200-40T-MIC
The MICs are separately orderable.
The EX9200-MPC line card has two slots on the faceplate in
which you can install the MICs. You can install the MICs in the
following configurations:
•
One EX9200-10XS-MIC
•
One EX9200-20F-MIC
•
One EX9200-10XS-MIC and one EX9200-20F-MIC
•
Two EX9200-10XS-MICs
•
Two EX9200-20F-MICs
•
One EX9200-40T-MIC
You can transmit up to 130 gigabits of traffic through the line
card without packet drop.
EX9200-MPC
See Figure 27 on page 59.
Figure 27: EX9200-MPC Line Card
3—1— MIC slots covered by cover panelsEjector lever
2—Line card LED
59Copyright © 2017, Juniper Networks, Inc.
Chapter 5: Line Cards
