Table 60: EX Series Switches Console Port Connector Pinout Information (continued)
DescriptionSignalPin
Data carrier detectCD Input7
Clear to sendCTS Input8
Related
Documentation
EX2200 Switches Hardware Overview•
• EX2300 Switches Hardware Overview
• Rear Panel of an EX3200 Switch
• Rear Panel of an EX3300 Switch
• Rear Panel of an EX3400 Switch
• Rear Panel of an EX4200 Switch
• EX4300 Switches Hardware Overview
• Front Panel of an EX4500 Switch
• EX4550 Switches Hardware Overview
• Management Panel of an EX4600 Switch
• Switch Fabric and Routing Engine (SRE) Module in an EX6200 Switch
• Switch Fabric and Routing Engine (SRE) Module in an EX8208 Switch
• Routing Engine (RE) Module in an EX8216 Switch
• Connecting a Switch to a Management Console
• Configuring the Console Port Type (CLI Procedure)
USB Port Specifications for an EX Series Switch
The following Juniper Networks USB flash drives have been tested and are officially
supported for the USB port on all EX Series switches:
•
RE-USB-1G-S
•
RE-USB-2G-S
•
RE-USB-4G-S
CAUTION: Any USB memory product not listed as supported for EX Series
switches has not been tested by Juniper Networks. The use of any
unsupported USB memory product could expose your EX Series switch to
unpredictable behavior. Juniper Networks Technical Assistance Center (JTAC)
can provide only limited support for issues related to unsupported hardware.
We strongly recommend that you use only supported USB flash drives.
Copyright © 2017, Juniper Networks, Inc.148
EX9208 Switch Hardware Guide
