Table 53: Optical Interface Support for 100-Gigabit QSFP+ Transceivers in EX9200 Switches

ValueSpecificationEthernet Standard

QSFP-100GBASE-SR4Model number100GBASE-SR4

100 GbpsRate

MPOConnector type

840 nm through 860 nmTransmitter wavelength

–8.4 dBm through 2.4 dBmAverage launch power per lane

–10.3 dBm through 2.4 dBmAverage receive power per lane

MMFFiber type

OM4OM3Fiber grade

100 m

(328 ft)

70 m

(230 ft)

Distance

AvailableDOM support

Junos OS for EX Series switches, Release 16.1R1 or

later

Software required
