Table 17: MIC LED for EX9200 Switches
State and DescriptionColorLED
On steadily—The MIC is functioning normally.GreenOK/FAIL
The MIC is not online.Unlit
On steadily—The MIC has failed.Red
Related
Documentation
EX9204 Switch Hardware Overview•
• EX9208 Switch Hardware Overview on page 3
• EX9214 Switch Hardware Overview
Routing Engine Module LEDs in an EX9200 Switch
Each Routing Engine module (RE module) has four LEDs on the module faceplate.
Table 18 on page 35 describes the functions of these LEDs.
Table 18: RE Module LEDs of an EX9200 Switch
State and DescriptionStatusLED Label
Routing Engine is functioning as the master.BlueMASTER
Routing Engine is either functioning as the backup
or not installed.
Unlit
Blinking—Indicates activity on the solid-state drive
(SSD) or the flash memory device.
GreenSTORAGE
•
On steadily—Routing Engine is operating
normally.
•
Blinking—Routing Engine is coming online or
going offline.
GreenONLINE
Routing Engine has failed.RedOK/FAIL
Related
Documentation
Switch Fabric Module in an EX9200 Switch on page 29•
• Installing an RE Module in an EX9200 Switch on page 223
• Removing an RE Module from an EX9200 Switch on page 225
Switch Fabric Module LEDs in an EX9200 Switch
The Switch Fabric module (SF module) has three LEDs on the module faceplate.
Table 19 on page 36 describes the functions of these LEDs.
35Copyright © 2017, Juniper Networks, Inc.
Chapter 2: Chassis Components and Descriptions
