Figure 94: Location of the Serial Number ID Label on EX9208 Switch

Chassis

g022017

ESD

Serial number ID label

Locating Serial Number ID Labels on FRU Components

The power supplies, fan tray, Routing Engine modules (RE modules), Switch Fabric

module (SF module), and line cards installed in an EX9200 switch are field-replaceable

units (FRUs). For each of these FRUs, you must remove the FRU from the switch chassis

to see the FRU’s serial number ID label.
