This topic describes the following tasks:
•
Holding a Line Card on page 238
•
Storing a Line Card on page 240
Holding a Line Card
You must hold a line card horizontally when installing it in the chassis. You may hold a
line card vertically or horizontally when carrying it.
CAUTION: The weight of line cards in EX9200 switches is in the range
14–19.4 lb (6.6–8.8 kg). Be prepared to support the full weight as you slide
the line card into the chassis.
To hold a line card vertically:
1. Orient the line card so that the faceplate faces you. To verify the orientation, confirm
that the text on the line card is right-side up.
2. Place one hand around the line card faceplate about a quarter of the way down from
the top edge. Do not press hard on it.
3. Place the other hand at the bottom edge of the line card.
If the line card is horizontal before you grasp it, place your left hand around the faceplate
and your right hand along the bottom edge.
To hold a line card horizontally:
1. Orient the line card so that the faceplate faces you.
2. Grasp the top edge with your left hand and the bottom edge with your right hand.
You can rest the faceplate of the line card against your body as you carry it.
CAUTION: Take care not to hit the line card against any object as you carry
it. Line card components are fragile.
Never hold or grasp the line card anywhere except the places mentioned in
these procedures. In particular, never grasp the connector edge. See
Figure 74 on page 239.
Copyright © 2017, Juniper Networks, Inc.238
EX9208 Switch Hardware Guide
