All USB flash drives used on EX Series switches must have the following features:
USB 2.0 or later.
Formatted with a FAT or MS-DOS file system.
If the switch is running Junos OS Release 9.5 or earlier, the formatting method must
use a master boot record. Microsoft Windows formatting, by default, does not use a
master boot record. See the documentation for your USB flash drive for information
about how your USB flash drive is formatted.
Related
Documentation
EX2200 Switches Hardware Overview
EX2300 Switches Hardware Overview
Rear Panel of an EX3200 Switch
Rear Panel of an EX3300 Switch
Rear Panel of an EX3400 Switch
Rear Panel of an EX4200 Switch
EX4300 Switches Hardware Overview
Front Panel of an EX4500 Switch
Management Panel of an EX4600 Switch
EX4550 Switches Hardware Overview
Switch Fabric and Routing Engine (SRE) Module in an EX6200 Switch
Switch Fabric and Routing Engine (SRE) Module in an EX8208 Switch
Routing Engine (RE) Module in an EX8216 Switch
Routing Engine Module in an EX9200 Switch on page 27
Booting an EX Series Switch Using a Software Package Stored on a USB Flash Drive
RJ-45 Management Port Connector Pinout Information
Table 61 on page 149 provides the pinout information for the RJ-45 connector for the
management port on Juniper Networks devices.
Table 61: RJ-45 Management Port Connector Pinout Information
DescriptionSignalPin
Transmit/receive data pair 1TRP1+1
Transmit/receive data pair 1TRP1-2
Transmit/receive data pair 2TRP2+3
Transmit/receive data pair 3TRP3+4
149Copyright © 2017, Juniper Networks, Inc.
Chapter 9: Pinout Specifications
