Chassis Physical Specifications of an EX9208 Switch
The EX9208 switch chassis is a rigid sheet-metal structure that houses the other switch
components. Table 7 on page 13 summarizes the physical specifications of the EX9208
switch chassis. See Figure 4 on page 15, Figure 5 on page 15, and Figure 6 on page 16.
Table 7: Physical Specifications of the EX9208 Switch Chassis
DepthWidthHeightWeightDescription
24.5 in. (62.2 cm) (from
front to chassis rear)
Total depth (including
cable management
brackets) 27.75 in.
(70.5 cm)
17.5 in. (44.5 cm)14.0 in. (35.6 cm)Chassis with midplane,
craft interface
(front-panel display),
fan tray, air filter, and
cable management
brackets: 65.5 lb
(29.7 kg)
Maximumconfiguration:
163.6 lb (74.2 kg)
Chassis
13Copyright © 2017, Juniper Networks, Inc.
