Table 7: Physical Specifications of the EX9208 Switch Chassis (continued)
DepthWidthHeightWeightDescription
7.75 in. (19.7 cm)11 in. (27.9 cm)1.25 in. (3.2 cm)2.4 lb (1.9 kg)Routing Engine
module (RE
module)
22 in. (55.9 cm)17 in. (43.2 cm)1.25 in. (3.2 cm)9.6 lb (4.4 kg) (with
Routing Engine
installed)
Switch Fabric
module (SF
module)
23.3 in. (59.2 cm)1.76 in. (4.5 cm)11.58 in. (29.4 cm)6.8 lb (3.84 kg)Fan tray
22.23 in. (56.5 cm)0.31 in. (0.8 cm)10.1 in. (25.7 cm)1.0 lb (0.5 kg)Air filter
4.5 in. (11.4 cm)0.25 in. (0.6 cm)9.9 in. (25.1 cm)0.3 lb (0.8 kg)Cable Management
Brackets
4 in. (10.2 cm)14.5 in. (36.8 cm)1.75 in. (4.4 cm)6.6 lb (2.99 kg)AC power supply
4 in. (10.2 cm)14.5 in. (36.8 cm)1.75 in. (4.4 cm)6.2 lb (2.81 kg)DC power supply
22 in. (55.9 cm)17 in. (43.2 cm)1.25 in. (3.2 cm)19.4 lb (8.8 kg)EX9200-2C-8XS
line card
22 in. (55.9 cm)17 in. (43.2 cm)1.25 in. (3.2 cm)16.8 lb (7.6 kg)EX9200-4QS line
card
22 in. (55.9 cm)17 in. (43.2 cm)1.25 in. (3.2 cm)21 lb (9.25 kg)EX9200-6QS line
card
22 in. (55.9 cm)17 in. (43.2 cm)1.25 in. (3.2 cm)15.96 lb (7.3 kg)EX9200-MPC line
card
7.86 in. (20 cm)6.67 in. (16.9 cm)1.25 in. (3.2 cm)1.54 lb (0.7 kg)EX9200-10XS-MIC
7.86 in. (20 cm)6.67 in. (16.9 cm)1.25 in. (3.2 cm)1.2 lb (0.54 kg)EX9200-20F-MIC
22 in. (55.9 cm)13.36 in. (33.9 cm)1.25 in. (3.2 cm)1.9 lb (0.9 kg)EX9200-40T-MIC
22 in. (55.9 cm)17 in. (43.2 cm)1.25 in. (3.2 cm15.7 lb (7.12 kg)EX9200-12QS line
card
22 in. (55.9 cm)17 in. (43.2 cm)1.25 in. (3.2 cm)19.2 lb (8.7 kg)EX9200-32XS line
card
22 in. (55.9 cm)17 in. (43.2 cm)1.25 in. (3.2 cm)14.0 lb (6.6 kg)EX9200-40T line
card
22 in. (55.9 cm)17 in. (43.2 cm)1.25 in. (3.2 cm)14.8 lb (6.7 kg)EX9200-40F line
card
Copyright © 2017, Juniper Networks, Inc.14
EX9208 Switch Hardware Guide
