Table 3: Line Cards Available for EX9208 Switches (continued)
Additional InformationDescriptionModel
“EX9200-6QS Line Card” on page 56A line card with six 40-Gigabit Ethernet
ports and 24 10-Gigabit Ethernet ports
EX9200-6QS
“EX9200-MPC Line Card” on page 58A modular line card that accepts any of
the following MICs:
•
EX9200-10XS-MIC
•
EX9200-20F-MIC
•
EX9200-40T-MIC
EX9200-MPC
“EX9200-12QS Line Card” on page 62A line card with six 40-Gigabit Ethernet
rate-selectableports, each of which can
house transceivers
EX9200-12QS
“EX9200-32XS Line Card” on page 64A line card with 32 10-Gigabit Ethernet
ports
EX9200-32XS
“EX9200-40T Line Card” on page 65A line cardwith 40 10/100/1000BASE-T
ports that support RJ-45 connectors
EX9200-40T
“EX9200-40F Line Card” on page 67A line card with 40 1-Gigabit Ethernet
ports
EX9200-40F
“EX9200-40F-M Line Card” on page 68A line card with 40 1-Gigabit Ethernet
ports with Media Access Control Security
(MACsec) capability
EX9200-40F-M
“EX9200-40XS Line Card” on page 70A line card with 40 10-Gigabit Ethernet
ports with Media Access Control Security
(MACsec) capability, each of which can
house 10-gigabit small form-factor
pluggable plus (SFP+) transceivers
EX9200-40XS
Cooling System
The cooling system in an EX9208 switch is a field-replaceable unit (FRU). It consists of
a hot-removable and hot-insertable fan tray. The fan tray contains six fans. The fan tray
installs vertically on the right back of the chassis and provides side-to-side chassis cooling.
See “Cooling System and Airflow in an EX9208 Switch” on page 39.
Power Supplies
Power supplies for the EX9208 switch are fully redundant, load-sharing, and
hot-removable and hot-insertable FRUs. Each EX9208 switch chassis can hold up to
four AC or DC power supplies.
Table 4 on page 7 shows the details of the power supplies available for EX9208 switches.
Copyright © 2017, Juniper Networks, Inc.6
EX9208 Switch Hardware Guide
