You can use the show version command to see the version of Junos OS for EX Series
switches loaded on the switch.
Line Card Components
The EX9200-MPC line card has:
•
Two slots that can accept any of the following MICs:
•
EX9200-10XS-MIC, which has ten 10-Gigabit Ethernet ports, each of which can
house small form-factor pluggable plus (SFP+) transceivers. The ports form one
port group. The ports support 10GBASE-SR, 10GBASE-LR, 10GBASE-ER, and
10GBASE-ZR transceivers. An LED labeled OK/FAIL on the MIC indicates the status
of the MIC. See “Modular Interface Card LED in an EX9200 Switch” on page 34. The
MIC is shipped with 10 dust covers for the 10 ports. See Figure 28 on page 60.
Figure 28: EX9200-10XS-MIC
3—1— MIC power buttonLEDs for the ports
4—2— MIC LED10-Gigabit Ethernet ports
•
EX9200-20F-MIC, which has twenty 1-Gigabit Ethernet ports with Media Access
Control Security (MACsec) capability, each of which can house 1-gigabit small
form-factor pluggable (SFP) transceivers. The EX9200-20F-MIC in EX9200-MPC
line card supports 802.1AE IEEE MAC Security standard (also known as MACsec)
with AES-128 bit encryption, providing support for link-layer data confidentiality,
data integrity, and data origin authentication. You must apply a single
license—EX9200-SFL—to enable MACsec. The ports are divided into two port groups
of ten ports each. The ports labeled [0/2]/0 through [0/2]/8 and [1/3]/0 through
[1/3]/8 form one port group and the ports labeled [0/2]/1 through [0/2]/9 and
[1/3]/1 through [1/3]/9 form another port group. These ports support 1000BASE-T,
1000BASE-SX, 100BASE-FX, 1000BASE-LX, 1000BASE-BX-U, 1000BASE-BX-D,
100BASE-BX-U, 100BASE-BX-D, and 1000BASE-LH transceivers. An LED labeled
OK/FAIL on the MIC indicates the status of the MIC. See “Modular Interface Card
LED in an EX9200 Switch” on page 34. The MIC is shipped with 20 dust covers for
the 20 ports. See Figure 29 on page 61.
Copyright © 2017, Juniper Networks, Inc.60
EX9208 Switch Hardware Guide
