Table 54: Optical Interface Support for CFP Transceivers in EX9200 Switches

ValueSpecificationEthernet Standard

CFP-100GBASE-SR10Model number100GBASE-SR10

MultimodeOptical interface

100 GbpsRate

IEEE 802.3ba—2010Standard

840 nm through 860 nmTransmitter wavelength

–7.6 dBm through 2.4 dBmAverage launch power

–9.5 dBm through 2.4 dBm for OM3

–9.1 dBm through 2.4 dBm for OM4

Average receive power

2.4 dBmReceiver saturation

–9.5 dBm for OM3

–9.1 dBm for OM4

Receiver sensitivity

MMFFiber type

OM3Fiber grade

100 m (328 ft)Distance

Not availableDOM support

Junos OS for EX Series switches, Release 13.2R1 or

later

Software required
