Table 54: Optical Interface Support for CFP Transceivers in EX9200 Switches (continued)
ValueSpecificationEthernet Standard
CFP-GEN2-100GBASE-LR4Model number100GBASE-LR4
Single-modeOptical interface
100 GbpsRate
IEEE 802.3ba-2010Standard
1294.53 nm through 1296.59 nm
1299.02 nm through 1301.09 nm
1303.54 nm through 1305.63 nm
1308.09 nm through 1310.19 nm
Transmitter wavelength
–4.3 dBm through 4.5 dBmAverage launch power
10.5 dBmMaximum launch power
–10.6 dBm through 4.5 dBmAverage receive power
4.5 dBmReceiver saturation
–10.6 dBmReceiver sensitivity
SMFFiber type
9/125 µmCore/Cladding size
10 km (6.2 miles)Distance
AvailableDOM support
Junos OS for EX Series switches, Release 13.2R1 or
later
Software required
Related
Documentation
Installing a Transceiver in a Switch on page 255•
• Removing a Transceiver from a Switch on page 257
• EX9200-2C-8XS Line Card on page 53
• EX9200-4QS Line Card on page 55
• EX9200-6QS Line Card on page 56
• EX9200-MPC Line Card on page 58
• EX9200-12QS Line Card on page 62
131Copyright © 2017, Juniper Networks, Inc.
Chapter 8: Transceiver and Cable Specifications
