WARNING: The switch is pluggable type A equipment installed in a
restricted-access location. It has a separate protective earthing terminal
(sized for UNC 1/4-20 ground lugs) provided on the chassis in addition to the
grounding pin of the power supply cord. This separate protective earthing
terminal must be permanently connected to earth.
CAUTION: Power cords must not block access to switch components. We
recommend that you route all AC power cord cables through the power cord
tray provided with the switch.
Related
Documentation
AC Power Supply in an EX9208 Switch on page 43•
• AC Power Electrical Safety Guidelines on page 353
• AC Power Disconnection Warning on page 355
• General Electrical Safety Guidelines and Warnings on page 349
• Connecting AC Power to an EX9208 Switch on page 179
• Connecting Earth Ground to an EX Series Switch on page 173
DC Power Supply Specifications for EX9208 Switches
Table 45 on page 96 lists the DC power supply specifications for EX9208 switches.
Table 45: DC Power Supply Specifications for an EX9208 Switch
Specifications
Item
Operating range:
•
Minimum operating range: –40.5 VDC
•
Nominal operating range: –48 VDC
•
Operating voltage range: –40.5 VDC to –72 VDC
DC input voltage
70 A (DIP=1)60 A (DIP=0)Maximum Input Current
2600 W2400 WMaximum output power
54.2 A @ –48 VDC normal
operating voltage
50 A @ –48 VDC normal
operating voltage
DC input current rating
Table 46 on page 97 lists the power system specifications for EX9208 switches.
Copyright © 2017, Juniper Networks, Inc.96
EX9208 Switch Hardware Guide
