Table 42: AC Power Supply Specifications for an EX9208
Switch (continued)
SpecificationsItem
•
Low-voltage line: 1167 W
•
High-voltage line: 2050 W
AC output power
Table 43 on page 93 lists the AC power system specification for an EX9208 switch.
Table 43: AC Power System Specifications
High-LineLow-LineItem
2+23+1Redundancy
2050 W1167 WOutput power (maximum) per power supply
4100 W3501 WOutput power (maximum) per system
Related
Documentation
AC Power Supply in an EX9208 Switch on page 43•
• AC Power Supply LEDs in an EX9208 Switch on page 45
• AC Power Cord Specifications for an EX9208 Switch on page 93
AC Power Cord Specifications for an EX9208 Switch
Each AC power supply has a single AC appliance inlet located on the power supply that
requires a dedicated AC power feed. Most sites distribute power through a main conduit
that leads to frame-mounted power distribution panels, one of which can be located at
the top of the rack that houses the switch. An AC power cord connects eachpower supply
to the power distribution panel.
You can order detachable AC power cords, each approximately 8 ft (2.44 m) long that
supply AC power to the switch. The C19 appliance coupler at the female end of the cord
inserts into the AC appliance inlet coupler, type C20 (right angle) as described by
International Electrotechnical Commission (IEC) standard 60320. The plug at the male
end of the power cord fits into the power source receptacle that is standard for your
geographical location.
Table 44 on page 93 provides specifications and Figure 39 on page 95 depicts the plug
on the AC power cord provided for each country or region.
Table 44: AC Power Cord Specifications for an EX9208 Switch
Plug Type
Electrical
SpecificationModel NumberCountry
SAA/3/15240 VAC, 50 Hz
AC
CBL-M-PWR-RA-AUAustralia
93Copyright © 2017, Juniper Networks, Inc.
Chapter 7: Planning Power Requirements
