CHAPTER 12
Connecting the Switch to Power
•
Connecting Earth Ground to an EX Series Switch on page 173
•
Connecting AC Power to an EX9208 Switch on page 179
•
Powering On an AC-Powered EX9200 Switch on page 182
•
Connecting DC Power to an EX9208 Switch on page 183
•
Powering On a DC-Powered EX9200 Switch on page 188
Connecting Earth Ground to an EX Series Switch
To ensure proper operation and to meet safety and electromagnetic interference (EMI)
requirements, you must connect an EX Series switch to earth ground before you connect
power to the switch. You must use the protective earthing terminal on the switch chassis
to connect the switch to earth ground (see Figure 50 on page 178).
WARNING: The switch is installed in a restricted-access location. It has a
separateprotective earthing terminalon the chassisthat must be permanently
connected to earth ground to adequately ground the chassis and protect the
operator from electrical hazards.
CAUTION: Beforeswitchinstallationbegins, ensure thata licensed electrician
has attached an appropriate grounding lug to the grounding cable that you
supply. Using a grounding cable with an incorrectly attached lug can damage
the switch.
This topic describes:
•
Parts and Tools Required for Connecting an EX Series Switch to Earth
Ground on page 174
•
Special Instructions to Follow Before Connecting Earth Ground to a Switch on page 177
•
Connecting Earth Ground to an EX Series Switch on page 178
173Copyright © 2017, Juniper Networks, Inc.
