NOTE: You can install up to six line cards (in any combination) in the switch.
NOTE: Line cards are not part of the base or redundant configuration. You
must order them separately.
NOTE: Power cords and additional power supplies (AC or DC) must be
purchased separately.
Related
Documentation
Chassis Physical Specifications of an EX9208 Switch on page 13•
• Routing Engine Module in an EX9200 Switch on page 27
• Switch Fabric Module in an EX9200 Switch on page 29
• AC Power Supply in an EX9208 Switch on page 43
• DC Power Supply in an EX9208 Switch on page 46
• Cooling System and Airflow in an EX9208 Switch on page 39
• EX9208 Switch Hardware Overview on page 3
EX9208 Switch Hardware and CLI Terminology Mapping
This topic describes the hardware terms used in EX9208 switch documentation and the
corresponding terms used in the Junos OS CLI. See Table 6 on page 9.
Table 6: CLI Equivalents of Terms Used in Documentation for EX9208 Switches
Additional
Information
Item in
DocumentationValue (CLI)Description (CLI)
Hardware
Item (CLI)
“Chassis Physical
Specifications of an
EX9208 Switch” on
page 13
Switch chassis–EX9208Chassis
“Midplane in an
EX9200 Switch” on
page 25
Switch midplane–EX9208-BPMidplane
“Craft Interface in an
EX9200 Switch” on
page 19
Craft Interface–Front Panel DisplayFPM Board
9Copyright © 2017, Juniper Networks, Inc.
Chapter 1: Switch Overview
