Table 5: EX9208 Switch Hardware Configurations (continued)
Configuration ComponentsSwitch Configuration
•
Chassis with front-panel display (craft interface) and
midplane
•
One Switch Fabric 2 module (SF2 module)
•
One Routing Engine module (RE module)
•
One fan tray
•
One air filter kit
•
Three 2520 W AC power supplies
•
One SF module cover panel
•
Six line card cover panels
•
Blank panels for empty power supply slots
EX9208-BASE3A-AC
(base configuration with 2520 W AC power supplies)
•
Chassis with craft interface and midplane
•
Two SF modules
•
Two RE modules
•
One fan tray
•
One air filter kit
•
Four 2520 W AC power supplies
•
Six line card cover panels
EX9208-REDUND-AC
(redundant configuration with 2520 W AC power supplies)
•
Chassis with craft interface and midplane
•
Two SF2 modules
•
Two RE modules
•
One fan tray
•
One air filter kit
•
Four 2520 W AC power supplies
•
Six line card cover panels
EX9208-REDUND3A-AC
(redundant configuration with 2520 W AC power supplies)
•
Chassis with craft interface and midplane
•
Two SF modules
•
Two RE modules
•
One fan tray
•
One air filter kit
•
Four 2400 W DC power supplies
•
Six line card cover panels
EX9208-REDUND-DC
(redundant configuration with 2400 W DC power supplies)
•
Chassis with craft interface and midplane
•
Two SF2 modules
•
Two RE modules
•
One fan tray
•
One air filter kit
•
Four 2400 W DC power supplies
•
Six line card cover panels
EX9208-REDUND3A-DC
(redundant configuration with 2400 W DC power supplies)
