Juniper EX9208 Hardware Guide

Table 16: Network Port LEDs on Line Cards in an EX9200 Switch—Status
LED
State, Color, and DescriptionLCD IndicatorLED
Indicates the administrative status (enabled or
disabled). The status indicators are:
•
Green—Administrative status enabled.
•
Yellow—The port is down.
•
Unlit—Administrative status disabled.
LED: ADMStatus
Indicates the speed. The speed indicators are
different in the line cards.
LED: SPD
•
Unlit—10 Mbps
•
Green—Blinking—100 Mbps
•
Green—On steadily—1000 Mbps
Indicates the duplex mode. The status
indicators are:
•
Green—Port is set to full-duplex mode.
•
Unlit—Port is not set to full-duplex mode.
LED: DPX
Related
Documentation
Line Card LED in an EX9200 Switch on page 71•
• Craft Interface in an EX9200 Switch on page 19
Modular Interface Card LED in an EX9200 Switch
The Modular Interface Cards (MICs) in the following line cards for EX9200 switches have
an LED labeled OK/FAIL on the faceplate that indicates the online status information of
MICs.
•
EX9200-4QS Line Card on page 55
•
EX9200-MPC Line Card on page 58
•
EX9200-40F Line Card on page 67
•
EX9200-40F-M Line Card on page 68
•
EX9200-40T Line Card on page 65
Table 17 on page 35 describes the MIC LED on line cards for EX9200 switches, its colors
and state, and the status it indicates.
Copyright © 2017, Juniper Networks, Inc.34
EX9208 Switch Hardware Guide
