Juniper EX9208 Hardware Guide

Table 6: CLI Equivalents of Terms Used in Documentation for EX9208 Switches (continued)
Additional
Information
Item in
DocumentationValue (CLI)Description (CLI)
Hardware
Item (CLI)
•
AC Power Supply in
an EX9208 Switch
on page 43
•
DC Power Supply in
an EX9208 Switch
on page 46
AC or DC power supplyn is a value in the range of
0–3. The value corresponds
to the power supply slot
number.
One of the following:
•
PS 1.4-2.52 kW;
90-264 V AC in
•
DC 2.4 kW Power
Entry Module
PEM(n)
“Routing Engine Module
in an EX9200 Switch”
on page 27
RE modulen is a value in the range 0–1.
In base configuration, only
one entry appears.
In redundant configuration,
two entries appear; one for
each Routing Engine module
(RE module) installed in the
chassis.
RE-S-EX9200-1800X4Routing
Engine (n)
“Switch Fabric Module
in an EX9200 Switch”
on page 29
SF modulen is a value in the range of
0–1.
Multiple line items appear in
the CLI if more than one
Switch Fabric modules (SF
modules) are installed in the
chassis.
CB0 and CB1 stand for SF
modules.
One of the following:
•
EX9200–SCBE
•
EX9200–SF2
CB (n)
•
EX9200-2C-8XS
Line Card on page 53
•
EX9200-4QS Line
Card on page 55
•
EX9200-6QS Line
Card on page 56
•
EX9200-MPC Line
Card on page 58
•
EX9200-32XS Line
Card on page 64
•
EX9200-40T Line
Card on page 65
•
EX9200-40F Line
Card on page 67
•
EX9200-40F-M Line
Card on page 68
Line card (The switch
does not have actual
FPCs—the line cards
are the FPC equivalents
on the switch.)
n is a value in the range of
0–5. The value corresponds
to the line card slot number
in which the line card is
installed.
Abbreviatedname of the
line card
One of the following:
•
EX9200-2C-8XS
•
EX92004x40GQSFP
•
EX9200
24x10GE+6x40GE
•
EX9200-MPC
•
EX9200 32x10G SFP
•
EX9200 40x1G
Copper
•
EX9200-40x1G-SFP
•
EX9200-40FE
FPC (n)
Copyright © 2017, Juniper Networks, Inc.10
EX9208 Switch Hardware Guide
