Table 51: Optical Interface Support for SFP+ Transceivers in EX9200 Switches (continued)

ValueSpecificationEthernet Standard

EX-SFP-10GE-ZRModel number10GBASE-ZR

10 GbpsRate

LCConnector type

DualFiber count

1550 nmTransmitter wavelength

0 dBmMinimum launch power

5 dBmMaximum launch power

–20 dBmMinimum receiver sensitivity

–8 dBmMaximum input power

SMFFiber type

9/125 µmCore/Cladding size

–Modal bandwidth

80 km (49.7 miles)Distance

AvailableDOM support

Junos OS for EX Series switches, Release 12.3R2 or laterSoftware required
