Table 58: QSFP+ Direct Attach Copper Cable Specifications (continued)
ValueSpecificationModel Number
40-Gbps full-duplex serial transmissionRateJNP-QSFP-DAC-5M
QSFP+ passive Twinax cable assemblyConnector type
3.3 VSupply voltage
0.015 WPower consumption (per end)
–40° C through 85° CStorage temperature
TwinaxCable type
26 AWGWire AWG
2.54 cm (1 in.)Minimum cable bend radius
100 ohmsCable characteristic impedance
1% maximumCrosstalk between pairs
4.3 nsec/ftTime delay
16.4 ft (5 m)Length
40-Gbps full-duplex serial transmissionRateJNP-QSFP-DAC-5MA
QSFP+ passive Twinax cable assemblyConnector type
3.3 VSupply voltage
0.015 WPower consumption (per end)
–40° C through 85° CStorage temperature
TwinaxCable type
30 AWGWire AWG
0.76 cm (0.3 in.)Minimum cable bend radius
100 ohmsCable characteristic impedance
2% maximumCrosstalk between pairs
4.3 nsec/ftTime delay
16.4 ft (5 m)Length
