Chapter 5: Changing the System Setup
MP65492–1 101 Linx 4900 Operating Manual
5.4 Changing the Line Settings
This section describes how to set the print trigger, enable a shaft encoder,
and configure the alarm settings and power down options.
5.4.1 To Set the Print Trigger
The Primary Trigger option allows you to specify the print trigger signal.
To set the print trigger:
Note that printing must be stopped to change the Primary Trigger option.
1. At the CURRENT MESSAGE screen, press the [F4] function key.
The SETUP menu is displayed.
2. Scroll through the menu options until the cursor rests at the Primary
Trigger option, as shown below:
Figure 5-10 Setup Menu: Primary Trigger Option
3. Press the [enter] key to select the option.
Set Time
Set Date
Julian Date Format
Primary Trigger
49072
SETUP
: 10:16
: 15:08:03
: European
: Leading Edge
>
4900 Op Manual.book Page 101 Tuesday, September 9, 2003 12:32 PM
