Chapter 3: Day-to-Day Operations
MP65492–1 31 Linx 4900 Operating Manual
To check the current line settings, and for further information about your
line setup, see Chapter 5, ‘Changing the System Setup’.
The following table shows when the printer actually prints, depending on
the settings configured for your production line:
Figure 3-6 Product Sensor/Shaft Encoder Printing Results
3.2.4 To Stop Printing
1. Press the [F1] function key:
The message “Stop Print : Please Wait” is displayed briefly in the
Status Line, then printing stops.
The options on the left side of the CURRENT MESSAGE screen are
redisplayed (see Figure 3-1 on page 26), and the printer status changes
to “Jet Running”.
49060
Product Sensor Shaft Encoder Printing result
Selected
Prints when Product Sensor is
triggered, and Shaft Encoder has
moved set distance.
Selected
Not selected
Prints when Product Sensor is
triggered.
Selected
Prints continuously when Shaft
Encoder has moved set distance.
Not selected
Not selected
Prints immediately and continuously
irrespective of presence of a
product.
4900 Op Manual.book Page 31 Tuesday, September 9, 2003 12:32 PM
