Linx 4900 - Ultima Plus Printhead

Appendix C: Line Speeds and Print Quality
MP65492–1 191 Linx 4900 Operating Manual
C.2.2 Ultima plus Printhead
Figure C-2 Ultima plus Printhead Maximum Line Speeds
49186
ULTIMA PLUS PRINTHEAD
Configuration
SS HS SHS
Message Type
Maximum line
speed at Ideal
Raster Pitch
(m/s)
●
5 Wide 7.28
● ● ●
7 Quality 1.61
● ●
7 Speed 3.42
● ●
7 Wide 5.20
● ● ●
16 Quality 0.54
● ●
16 Speed 0.78
●
16 Wide 1.05
