Appendix A: Installation and Setup
MP65492–1 159 Linx 4900 Operating Manual
A.4.1 To Connect a Product Sensor
You must connect the product sensor to the printer using a 9-pin D-type
connector. The following table describes the function of each pin:
Figure A-4 Product Sensor Pin Connections
The product sensor cable has a braided screen. You must connect the
screen to the shell of the connector, which is in turn connected to the
printer chassis. You must not connect the screen to 0 volts.
CAUTION: EMC performance may be compromised by the use of
unsuitable product sensors and cables. Use only Linx approved
accessories.
49299
Function Connection
+ 24 V Pin 1
0 V Pin 2
Not used Pin 4
Primary Trigger Pin 6
