Appendix C: Line Speeds and Print Quality
Linx 4900 Operating Manual 190 MP65492–1
C.2 Printable Line Speeds
The following tables show the maximum line speed at which good printing
will be obtained for each printer configuration, printhead type and message
type at Ideal Raster Pitch.
C.2.1 Ultima Printhead
Figure C-1 Ultima Printhead Maximum Line Speeds
49080
KEY
Configuration:
SS
HS
SHS
= Standard Speed
= High Speed
= Super High Speed
Message Types:
5, 7, etc. = Raster or Pixel height of a Message Type
49004
ULTIMA PRINTHEAD
Configuration
SS HS SHS
Message Type
Maximum line
speed at Ideal
Raster Pitch
(m/s)
●
5 Wide 6.25
● ● ●
7 Flexible 1.99
●
●
●
7 Quality 2.01
●
●
7 Speed 3.53
● ●
7 Wide 4.69
●
●
●
16 Flexible 0.63
● ● ●
16 Quality 0.56
●
●
16 Speed 0.82
●
16 Wide 1.44
