Chapter 4: Creating and Editing Messages
Linx 4900 Operating Manual 56 MP65492–1
4.3 Getting to Know the EDIT
MESSAGE Screen
You use the EDIT MESSAGE screen to create and edit all types of
messages. The following example shows you the main features and
indicators:
Figure 4-9 Edit Message Screen Features and Indicators
Feature/indicator... Description...
A
Message Cursor
Shows current cursor position. See the
Message Cursor ‘About’ box below.
B Message Display Area Area where the message being created or
edited is displayed, and where you work on
the message.
C Message Name The name of the message being created or
edited.
D
Options
Allow you to perform message editing
functions by pressing the associated
function key:
Press [F1] to select the character size.
Press [F2] to switch the bold ratio on or
off.
Press [F3] to specify the field (Time,
Timed Message, Sequential Number, Date,
Remote or Logo field).
Press [F4] to save the message and exit
from the screen, back to the CURRENT
MESSAGE screen.
49117
B
F1 : Size 7 FH (Caps)
F3 : Field Type
F2 : Bold Off
F4 : Save & Exit
EDIT MESSAGE : MESSAGE 1
Sell by
LINX
C
D
A
4900 Op Manual.book Page 56 Tuesday, September 9, 2003 12:32 PM
