Appendix A: Installation and Setup
MP65492–1 155 Linx 4900 Operating Manual
A.2 Connecting to a Power Source
The Linx 4900 printer has a power rating of 200 VA, and operates on a
single-phase, 50/60 Hz a.c. supply of 100 V to 230 V. This means that any
a.c. voltage within this range will power the printer satisfactorily.
Refer to Appendix F, ‘Technical Specification’ for a detailed specification
of the Linx 4900 printer.
NOTE: Please check that the details shown on the label at the rear of the
printer match your power source before switching on.
Before you connect the printer to the mains power supply, make sure that
the mains power supply switch (rocker switch) is in the ‘0’ (off) position.
IMPORTANT: For the printer to comply with EN60204–1:1997. Safety of
machinery. Electrical equipment of machines. Specification
for general requirements, the printer must be connected to
the mains supply in one of the following two ways:
1. By using a plug and socket arrangement.
2. If the printer is hard wired to the mains supply, a mains
disconnecting device must be used between the printer
and the mains supply.
The wires in this electrical supply lead are coloured in accordance with the
following code:
WARNING: THIS PRINTER MUST BE EARTHED.
WARNING: THIS PRINTER MUST BE ELECTRICALLY
WIRED ONLY BY A QUALIFIED AND COMPETENT
ELECTRICIAN. LINX CANNOT ACCEPT RESPONSIBILITY
FOR ANY INJURY OR DAMAGE TO PERSONNEL OR
MACHINERY DUE TO INCORRECT OR FAULTY WIRING.
Wire Colour Connection
Green-Yellow Earth
Blue Neutral
Brown Live
See Also
4900 Op Manual.book Page 155 Tuesday, September 9, 2003 12:32 PM
